3-D ONLINE ANIMATION OF SIMULATED MECHANICAL SYSTEMS IN REAL TIME



MotionDesk helps you get more out of your HIL simulator, visualizing your simulation in virtual worlds that exactly represent the simulation scenarios.

  • Tight integration with ModelDesk and ASM
  • Intuitive graphical scene design
  • Enhanced support for all aspects of advanced driver assistance systems (ADAS)

DESCRIPTION

Application Areas

When you develop a mechatronic control system such as an advanced driver assistance system, you need to be certain that it performs correctly. You can do this by running HIL simulations. The best way to understand the behavior of a simulated system is to use animated visualization in realistic 3-D scenes. Combining a simulation system with real-time animation is the ideal way to get the whole picture. Since animations can be recorded and replayed, it is easy to compare different controller development strategies by using overlay techniques. MotionDesk enhances the dSPACE tool chain by visualizing how mechanical objects move in the 3-D world. MotionDesk is the perfect tool to visualize any kind of vehicle dynamics development and driving maneuvers, such as lane change, split-µ, and cornering.

MotionDesk

Key Benefits

MotionDesk helps you get more out of your HIL simulator, visualizing your simulation in virtual worlds that exactly represent the simulation scenarios. MotionDesk reads the data from the HIL simulator and displays the animation of the moving objects (vehicle, wheels, steering wheel, etc.) in real time, using the perspectives and render modes that you choose yourself, to give you a clear understanding of how the simulated objects actually behave. You can store the animations as experiment files and record video files to document and illustrate your developments.

MotionDesk

SUPPORT OF ADVANCED DRIVER ASSISTANCE SYSTEMS

MotionDesk provides enhanced support for all aspects of advanced driver assistance systems (ADAS), where the complexity of an action has to be seen to be understood. When an ADAS is tested, the visualization must be realistic enough for object recognition, and a high frame rate is crucial. MotionDesk’s rendering engine guarantees detailed and realistic visualization. Even complex scenes can be rendered at a steady rate of 60 frames per second and beyond..

MotionDesk
<ul><li>Powerful rendering engine</li><li>Low latency between simulation and animation</li><li>Intuitive motion model to accurately position the observer in the scene</li>&lt/ul>
Multitrack mode
  • Powerful rendering engine
  • Force vector visualization
  • Low latency between simulation and animation
  • Intuitive motion model to accurately position the observer in the scene
